Serial uninterruptible power supply conversion cable
The serial uninterruptible power supply conversion cable changes signals to serial for use with the IBM
System i5 or eServer i5 model or logical partition. This cable is required if you are connecting the server
to an uninterruptible power supply.
Before you use this feature (feature code 1827), ensure that you have applied any prerequisite software.
For more information, see the IBM Prerequisite Web site.
To connect the serial uninterruptible power supply conversion cable, do the following:
1. Connect side B (see the following figure) of the serial uninterruptible power supply conversion cable
(with the external threads) to system port 2 (P1-T2) on the back of your system.For back views of the
520, 525, and 515 models, see References.
2. Connect side A of the serial uninterruptible power supply conversion cable (with the internal threads)
to the vendor-supplied uninterruptible power supply cable.
Cabling your server 247
