Routing and Securing Cables
To route and secure the cables, use the following descriptions.
I/O Drawer Cables: Use two screws (2) to connect the RIO drawer cables to the I/O
drawer and secure the cables with the RIO cable retainer (3).
Use the cable hanging brackets (1) as needed to hold the cables.
Route the cables over the cable guides and secure the cables with Velcro strips.
1
2
3
Chapter 1. Setting Up the System 21
