riser card, or the adapter.
PCI riser-card assembly
Adapter
f. Close the PCIe retention latch.
g. Install the riser-card assembly in the server (see “Installing a PCIe riser-card
assembly” on page 65).
8. Perform any configuration tasks that are required for the adapter.
If you have other devices to install or remove, do so now. Otherwise, go to
“Completing the installation” on page 116.
Installing the ServeRAID M1115 SAS/SATA Controller
Port 1 Port 0 ServeRAID M1115 adapter
The ServeRAID M1115 SAS/SATA Controller for IBM System x adapter can be
installed only in the PCIe slots listed in “Supported adapters” on page 68. The
ServeRAID M1115 SAS/SATA controller provides RAID levels 0, 1, and 10. You can
upgrade to RAID level 5 with the purchase of the optional RAID flash/cache
adapters or software feature. For configuration information, see the ServeRAID
documentation at http://www.ibm.com/supportportal/.
Chapter 2. Installing optional devices 73
