PANEL DESCRIPTION
■ Programmable function keys
The following functions can be assigned to [Top], [Side1],
, , and programmable function keys with
the optional CS-41S
CLONING SOFTWARE
.
The key function activates after pushing [Function] when the
programmable function key is assigned to the function mode
operation.
If the programmable function names are bracketed in the fol-
lowing explanations, the specific key is used to activate the
function depends on the programming.
Scan/Scan Tag
➥ Push to start/stop the scan.
➥ Push and hold for 2 sec. to set or clear the displayed chan-
nel as a TAG channel.
Scan Mode/Rpt Scan
➥ Push to select the scan mode.
➥ Push and hold for 2 sec. to start repeater scan.
PRIO/PRIO Set
➥ Push to select the priority channel.
➥ Push and hold for 2 sec. to set the displayed channel as
the priority channel.
S-Ring/PRIO Clear
➥ Push to transmit the Smart-Ring call.
• When RX channel is selected, “N/A” appears.
➥ Push and hold for 2 sec. to cancel the priority channel set-
ting.
Monitor/TSQL
(This key function can be assigned in the Normal mode only.)
➥ Push to toggle the monitor function ON or OFF.
➥ Push and hold for 2 sec. to activate the following functions
in order.
• Subaudible tone encoder and Tone squelch/DTCS squelch
• Pocket beep
• No tone operation.
RF Power/Lock
➥ Push to toggle the transmit output power level.
➥ Push and hold for 2 sec. to toggle key lock function ON and
OFF.
TX Code CH/Call
➥ Push to enter the TX code channel selection mode, then
push [CH Up] or [CH Down] to select the desired channel
(CB channel operation only).
➥ Push and hold for 2 sec. to transmit the specified SelCall
TX code in the selected channel (CB channel operation
only).
