Icom IC-7100 Service Manual

4-7
ADJUSTMENT ITEM TRANSCEIVER'S CONDITION OPERATION
ADJUST
POINT
VALUE
PREPARATION 1
–
• Connect the AG and millivoltmeter to
[MIC], and then set it as;
Frequency : 1.5 kHz
Level : 30 mVrms
• Connect a power meter to [ANT2].
–
Push [NB].
TX TOTAL GAIN
ADJUSTMENT
[UHF BAND]
Push [NR] to enter the Transmit menu.
2 • Display: "Total Gain UHF" • Push [SET]. (Automatically starts to
transmit.)
[MAIN DIAL]
17.5 W
Push [SET]*.
TX POWER &
POWER METER SETTING
3 • Display: "POWER UHF" – Push [SET].
(Automatically starts
to transmit.
4 • Display: "POWER UHF Min"
• Transmit continues
2 W
Push [SET].
5 • Display: "POWER UHF 10%"
• Transmit continues
3.5 W
Push [SET].
6 • Display: "POWER UHF 50%"
• Transmit continues
17.5 W
Push [SET].
7 • Display:
"POWER UHF 100%"
• Transmit continues
35 W
Push [SET]*.
ALC METER 8 • Display: "ALC UHF" – Push [SET].
(Automatically starts
to transmit.
A beep sounds, and
then another beeps
sound 3 sec. later.*)
DRIVE GAIN 9 • Display: "DRIVE UHF"
SWR METER 10 • Display: "SWR UHF" • Connect the 100
Ω
dummy load to
[ANT2].
The transmit adjustment menu is displayed.
Push [MIC/RF PWR] to return to the main adjustment menu.
4-7 TRANSMIT ADJUSTMENTS (UHF BAND)
4-6 TRANSMIT ADJUSTMENTS (VHF BAND)
ADJUSTMENT ITEM TRANSCEIVER'S CONDITION OPERATION
ADJUST
POINT
VALUE
PREPARATION 1
–
• Connect the AG and millivoltmeter to
[MIC], and then set it as;
Frequency : 1.5 kHz
Level : 30 mVrms
• Connect the power meter to [ANT2].
–
Push [NB].
TX TOTAL GAIN
ADJUSTMENT
(VHF BAND)
Push [NB] to enter the Transmit menu.
2 • Display: "Total Gain VHF" • Push [SET]. (Automatically starts to
transmit.)
[MAIN DIAL] 25 W
Push [SET]*.
TX POWER &
POWER METER SETTING
(VHF BAND)
3 • Display: "POWER VHF" –
–
Push [SET].
(Automatically starts
to transmit.
4 • Display: "POWER VHF Min" [MAIN DIAL] 2 W
Push [SET].
5 • Display: "POWER VHF 10%"
• Transmit continues
5 W
Push [SET].
6 • Display: "POWER VHF 50%"
• Transmit continues
25 W
Push [SET].
7 • Display:
"POWER VHF 100%"
• Transmit continues
50 W
Push [SET]*.
ALC METER
(VHF BAND)
8 • Display: "ALC VHF"
–
Push [SET].
(Automatically starts
to transmit.
A beep sounds, and
then another beeps
sound 3 sec. later.*)
DRIVE GAIN
(VHF BAND)
9 • Display: "DRIVE VHF"
SWR METER
(VHF BAND)
10 • Display: "SWR VHF" • Connect the 100
Ω
dummy load to
[ANT2].
The Transmit adjustment menu is displayed.
1) Set or modify the adjustment value as specifi ed by rotating [MAIN DIAL].
2) Push [SET] to store the value.
1) Set or modify the adjustment value as specifi ed by rotating [MAIN DIAL].
2) Push [SET] to store the value.
*; Stop transmitting.
*; Stop transmitting.
