6-1
[MAIN PARTS]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J1* 6510023720 LGY6501-0600C 1
J11* 6510027740 HSJ2462-010010 1
J31* 6450001641 TCS5044-0141177 1
J111* 6450001841 TCS7568-4320177 1
J151* 6510029830 3008S-8824 (50U) <KIN> 1
J171* 6510023110 3008L-8P8C <KIN> 1
J191* 6510023720 LGY6501-0600C 1
J261* 6510028980 SCDABA0500 1
J301* 6510024880 52689-3087 1
J401* 6510024880 52689-3087 1
J501* 6510028200 UB-M5BR-S14-4S (LF) (SN) 1
J571* 6510023720 LGY6501-0600C 1
J3001* 6510018450 TMP-S01X-B1 1
J5002* 6510025840 AXN316C038P 1
J5501* 6510027111 08FLT-SM2-TB (LF) (SN) (M) 1
J6501* 6510024522 12FLT-SM2-TB (LF) (SN) (M) 1
J6502* 6510025142 10FLT-SM2-TB (LF) (SN) (M) 1
BT6201* 3020000390 ML414HIV01E 1
EP2004* 6910002161 CASE-BM7H-LF 1
EP2206* 6910002161 CASE-BM7H-LF 1
EP2211* 6910002161 CASE-BM7H-LF 1
EP2404* 6910002161 CASE-BM7H-LF 1
EP2756* 6910002161 CASE-BM7H-LF 1
MP221* 8510020800 3393 C-SHIELD PLATE Y1292 1
MP401* 8930071160 2427 F-EARTH SPRING Y896 1
MP501* 8930071160 2427 F-EARTH SPRING Y896 [EUR] 1
8930071160 2427 F-EARTH SPRING Y896 [EUR-01] 1
8930071160 2427 F-EARTH SPRING Y896 [ITR] 1
8930071160 2427 F-EARTH SPRING Y896 [ESP] 1
8930071160 2427 F-EARTH SPRING Y896 [FRA] 1
MP1001* 8510020100 3182 DC-DC CASE Y1220 1
MP2101* 8510020790 3393 B-SHIELD PLATE <KN> 1
MP2102* 8510020800 3393 C-SHIELD PLATE Y1292 1
MP2201* 8510020800 3393 C-SHIELD PLATE Y1292 1
MP2202* 8510020790 3393 B-SHIELD PLATE <KN> 1
MP2301* 8510020830 3393 D-SHIELD PLATE Y1295 1
MP2501* 8510020780 3393 A-SHIELD PLATE <KN> 1
MP3031* 8510020800 3393 C-SHIELD PLATE Y1292 1
MP3231* 8510020770 3393 A-SHIELD CASE <KN> 1
MP3232* 8510020840 3393 E-SHIELD PLATE Y1296 1
MP4001* 8510020800 3393 C-SHIELD PLATE Y1292 1
MP4002* 8930071160 2427 F-EARTH SPRING Y896 1
MP4302* 8510012400 2177 D/A CASE Y454 1
MP5051* 8510020800 3393 C-SHIELD PLATE Y1292 1
SECTION 6
MECHANICAL PARTS
*: Refer to “BOARD LAYOUTS” for the location.
**: Refer to “GENERAL WIRING” for the connection
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[CHASSIS UNIT]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J1 6510028410 MR-DS-01-1 <GA> 1
J2 6510028410 MR-DS-01-1 <GA> 1
MF1 2710000790 AFB0512HB-4L50 <USE>HK 1
W1** 8910000140 FFC-1015 (P0.5N30L80) 1
W2** 8910000140 FFC-1015 (P0.5N30L80) 1
W3** 8900016990 OPC-1741 (1.5DCOAXIAL110MM) 1
W5** 8900019320 OPC-2034 1
W6** 8600037380 SX3183 J1101*P1102CH 1
MP1 8010022550 3393 CHASSIS 1
MP2 8110010360 3393 U-COVER Y2168 1
MP3 8110010370 3393 L-COVER Y2167 1
MP4 8210028270 3393 CHASSIS PANEL 1
MP5 8930086820 3393 FAN HOLDER <KN> 1
MP6 8310081740 3393 NAME PLATE 1
MP11 8930087840 3393 ANT PLATE Y1291 2
MP12 8930066431 2427 A-NET-1 1
MP13 8930079690 RUBBER STAND (Q) 4
MP14 8810008661 PHBT M3 X 8 NI-ZC3 11
MP15 8810008661 PHBT M3 X 8 NI-ZC3 12
MP16 8810008661 PHBT M3 X 8 NI-ZC3 4
MP17 8810009061 FLAT M3 X 6 ZK3 9
MP18 8810009061 FLAT M3 X 6 ZK3 9
MP19 8820000530 FLANGE BOLT M4 X 8 NI 1
MP20 8850000140 FLAT WASHER M 4 NI BS 1
MP22 8810008661 PHBT M3 X 8 NI-ZC3 2
MP23 8810010780 PH BT M3 X20 NI-ZK3 4
MP24 8810003171 SET SCREWA M3 X 8 ZC3 1
MP25* 8810003171 SET SCREWA M3 X 8 ZC3 4
MP26 8810003381 SET SCREWC M3 X10 ZC3 2
MP27* 8810003361 SET SCREWC M3 X 6 ZC3 2
MP28 8930068370 2427 A-MAGNETIC SHIELD 1
MP30* 8930078840 SHIELD SPONGE (CM) 1
MP31* 8930082340 SHIELD SPONGE (CR) 1
MP32* 8930082340 SHIELD SPONGE (CR) 1
MP33* 8930082340 SHIELD SPONGE (CR) 1
MP34* 8930082340 SHIELD SPONGE (CR) 1
MP35 6910008240 59TN4772 (SPCC) 1
MP36* 8930082340 SHIELD SPONGE (CR) 1
MP37* 8930088280 FERRITE SHEET (AL) 1
MP38 8930088330 FERRITE SHEET (AM) 1
MP39* 8930088000 SPONGE (MH) 1
MP40 8930063000 THERMAL SHEET (AQ) TC-700HS-1.4 1
MP41 8930064840 SHIELD SPONGE (AO) [USA] 1
8930064840 SHIELD SPONGE (AO) [EUR] 1
8930064840 SHIELD SPONGE (AO) [EUR-01] 1
8930064840 SHIELD SPONGE (AO) [ITR] 1
8930064840 SHIELD SPONGE (AO) [ESP] 1
8930064840 SHIELD SPONGE (AO) [FRA] 1
MP42 8930064840 SHIELD SPONGE (AO) [USA] 1
8930064840 SHIELD SPONGE (AO) [EUR] 1
8930064840 SHIELD SPONGE (AO) [EUR-01] 1
8930064840 SHIELD SPONGE (AO) [ITR] 1
8930064840 SHIELD SPONGE (AO) [ESP] 1
8930064840 SHIELD SPONGE (AO) [FRA] 1
MP43 8930048971 SHIELD TAPE (C)-1 [USA] 1
8930074740 SHIELD SPONGE (CE) [EUR] 1
8930074740 SHIELD SPONGE (CE) [EUR-01] 1
8930074740 SHIELD SPONGE (CE) [ITR] 1
8930074740 SHIELD SPONGE (CE) [ESP] 1
8930074740 SHIELD SPONGE (CE) [FRA] 1
MP44* 8930068000 SHIELD SPONGE (AT) [USA] 1
8930068000 SHIELD SPONGE (AT) [EUR] 1
8930068000 SHIELD SPONGE (AT) [EUR-01] 1
8930068000 SHIELD SPONGE (AT) [ITR] 1
8930068000 SHIELD SPONGE (AT) [ESP] 1
8930068000 SHIELD SPONGE (AT) [FRA] 1
MP45 8930057790 SHIELD SPONGE (K) [EUR] 1
8930057790 SHIELD SPONGE (K) [EUR-01] 1
8930057790 SHIELD SPONGE (K) [ITR] 1
8930057790 SHIELD SPONGE (K) [ESP] 1
8930057790 SHIELD SPONGE (K) [FRA] 1
MP46 8930057790 SHIELD SPONGE (K) [EUR] 1
8930057790 SHIELD SPONGE (K) [EUR-01] 1
8930057790 SHIELD SPONGE (K) [ITR] 1
8930057790 SHIELD SPONGE (K) [ESP] 1
8930057790 SHIELD SPONGE (K) [FRA] 1
MP47* 8930082340 SHIELD SPONGE (CR) Only [USA] 1
MP48* 8930068000 SHIELD SPONGE (AT) Only [USA] 1
MP49* 8930057870 2429 EARTH SPRING Only [USA] 1
MP50** 8930018700 THERMAL SHEET Z Only [USA] 1
MP51** 8930018700 THERMAL SHEET Z Only [USA] 1
