2-1
SECTION 2
.
INSIDE VIEWS
• DISPLAY UNIT
(TOP VIEW)
AF MUTE SW
(Q403)
FRONT CPU CLOCK
(X201)
DC-DC CONVERTER
(IC701)
AF MUTE SW
(Q404)
KEY BACKLIT DRIVER
(IC601)
LED DRIVER
(IC901)
