Icom IC-905 Reference Guide

21
REMOTE CONTROL
Remote control (CI-V) information
D Command formats
• UTC O󰀨set setting
Command: 1A 05 01 81
Shift direction
00=+ (plus)
01=− (minus)
Offset time
00 00 ~ 14 00
XX X X XX
• Color settings
Command: 1A 05 01 91, 01 92, 01 93, 02 24,
02 26, 02 42, 02 46, 02 47
1
0 X X X 0 X X X 0 X X X
2 3 4 5 6
R (Red)
00 00 ~ 02 55
G (Green)
00 00 ~ 02 55
B (Blue)
00 00 ~ 02 55
• Bandscope edge frequency settings
Command: 1A 05 01 99 ~ 02 22
1
X 0 X X X X X X 0 X X 0
2 3 4 5 6
Lower edge Higher edge
X X X X
7 8
9 
100 Hz: 0 (fixed) 100 kHz: 0
~ 9
10 kHz: 0
~ 9
10 MHz: 0
~ 9
1 MHz: 0
~ 9
1 GHz: 0, 1, 2, 5 100 MHz: 0
~ 9
1 kHz: 0
~
9
X X 0 X
100 GHz: 0 (fixed) 10 GHz: 0
, 1
100 Hz: 0 (fixed) 100 kHz: 0
~ 9
10 kHz: 0
~ 9
10 MHz: 0
~ 9
1 MHz: 0
~ 9
1 GHz: 0, 1, 2, 5 100 MHz: 0
~ 9
1 kHz: 0
~ 9
100 GHz: 0 (fixed) 10 GHz: 0
, 1
• Manually entered position data
Command: 1A 05 02 69, 02 95, 03 09,
23 02
10 degree digit: 0 ~ 9
1 degree digit: 0 ~ 9 10 minute digit: 0 ~ 5 1 minute digit: 0 ~ 9 0.1 minute digit: 0 ~ 9 0.01 minute digit: 0 ~ 9 0.001 minute digit: 0 ~ 9 0 (Fixed) 0 (Fixed) South latitude=0/North latitude=1 0 (Fixed) 100 degree digit: 0 ~ 1 10 degree digit: 0 ~ 9 1 degree digit: 0 ~ 9 10 minute digit: 0 ~ 5 1 minute digit: 0 ~ 9 0.1 minute digit: 0 ~ 9 0.01 minute digit: 0 ~ 9 0.001 minute digit: 0 ~ 9 0 (Fixed) 0 (Fixed) West longitude=0/East longitude=1
Latitude Longitude
10000 meter digit: 0 ~ 1 1000 meter digit: 0 ~ 9 100 meter digit: 0 ~ 9 10 meter digit: 0 ~ 9 1 meter digit: 0 ~ 9 0.1 meter digit: 0 ~ 9 0 (Fixed)
+=0/–=1
Altitude
1
X X X X X X X 0 0 X 0 X X X X X X X X 0 0 X X X X X X X 0 X
2 3 4 5 6 7 8 9      
* * * *
:
X X X X
6 ~ 
∙∙∙∙∙∙∙
X X X X
 ~ 
∙∙∙∙∙∙∙
X X
∙∙∙∙∙∙∙
X X
1 ~ 5
1 ~ 5: Latitude (dd°mm�mmm format)
6 ~ : Longitude (ddd°mm�mmm format)
 ~ : Altitude (0�1 meter steps)
* When reading the contents with no altitude, sends , ,
, and  as “FF�”
* When sending the contents with no altitude, set , , ,
and  to “FF�”
• D-PRS Symbol setting
Command: 1A 05 02 74 ~ 02 77, 02 93,
03 07, 03 18
First digit Second digit
XX X X
• 
character�
• See “Codes for character entries” for the second
digit character� (p� 19)
• Alarm area (Group) setting
Command: 1A 05 03 29
1
XX X X 0
2 3
X
10 min. digit: 0 ~ 5 1 min. digit: 0 ~ 9 0.1 min. digit: 0 ~ 9 0.01 min. digit: 0 ~ 9 0.001 min. digit: 0 ~ 9 0 (fixed)
