16
4
BASIC OPERATION
New2001
■ Plotter display operation (Continued)
D Setting the display type (North up/COG up)
Select the display type between “North up” and “COG up.”
q Push [MENU] to enter the Menu mode.
w Push [∫] or [√] to select “North up/COG up,” then push
[ENT].
e Push [ENT] to select either “North up” or “COG up.”
• You can also select the option by pushing [Ω] or [≈].
North up : The top of the plotter display represents North.
COG up : The top of the plotter display represents the di-
rection your course is heading.
r Push [CLEAR] to save and return to the Menu mode.
t Push [CLEAR] to exit the Menu mode.
[CLEAR]
[ENT]
[MENU]
[∫], [√],
[Ω], [≈]
■ Target list display operation
The target list display shows all AIS targets being detected
by the transponder, including their range and bearing infor-
mation.
The AIS target data is sorted by the distance from your ves-
sel, and the closest target is located on the top of the list.
Their range and bearing information is automatically updated
every 5 seconds, then the AIS target data is sorted.
qPush [DISP MODE] several times to select the target list
display.
w Push [∫] or [√] to select the desired AIS target.
e Push [ENT] to display it’s detail screen. (p. 17)
NOTE: The alarm buzzer sounds when a malfunction oc-
curs or an AIS target is closer than your CPA and TCPA
settings, depending on the presetting. (pp. 31, 32, 35, 46)
➥ To stop the alarm buzzer, push [CLEAR].
• If the popup screen is displayed, push [CLEAR] again to turn
it OFF.
