Icom MA-500TR User Manual

30
New2001New2001
MENU MODE OPERATION
6
■ General
q Push [MENU] to enter the Menu mode.
w
Push [∫] or [√] to select the desired item, then push [ENT].
e Select the desired option or check the screen contents.
The procedures are described on pages 31 to 36.
• Some items are not described in this section. See the list to the
right for the specified pages.
r Repeat steps w and e to select or check other items.
t Push [CLEAR] to exit the Menu mode.
[CLEAR]
[ENT]
[MENU]
[∫]
[√]
■ Menu mode items
The Menu mode contains the following items.
Item Ref. Item Ref.
North up/COG up* p. 16 User Setting
CPA/TCPA • RCV MSG BUZZ p. 35
• Alarm p. 31 • Internal GPS p. 35
• Slow Warn p. 31 - SBAS Function p. 36
• CPA, TCPA p. 32 Initial Setting
Message • Set MMSI* pp. 7, 9
• RX Log* p. 25 • Set Name*
pp. 9, 13
Waypoint • Set Call Sign* pp. 9, 13
• List* p. 26 • Set INT GPS POS* p. 10
• Add* p. 26 •
Set EXT GPS POS * p. 10
• Edit* p. 28 • Set Type of Ship* p. 10
• Delete* p. 29 • Set Input/Output* p. 11
Own Static p. 32 Channel Information p. 36
Own Dynamic p. 33 Diagnostics
GPS Information p. 33 • Monitor Test* p. 46
Alarm Status p. 34 • Transponder Test* p. 47
User Setting • Version Information* p. 47
• Key Beep p. 34
• Alarm Buzzer p. 35
*These items are not described in this section. See the specified page.
