49
10
TEMPLATE
New2001
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Cut here
Unit: mm (inch)
165 (6
1
⁄2)
110 (4
11
⁄32)
146 (5
3
⁄4)
92.4 (3
5
⁄8)
R12 (Max.)
