Idex HALE MIV 2.0 User Manual

44
Table 7. PARTS LIST
Item
Part Number
Qty
Name of Part
1
505-0230-00-0
1
MIV DISC
2
082-30100-611
5
PLUG, 1/8 BSPP, PLTD BRASS
3
038-1741-00-0
1
MIV VALVE BODY
4
217-0501-00-0
1
PLUG-3/4 NPT M.I.
5
046-0050-00-0
1
GASKET, 115 FLANGE
6
018-1812-02-0
4
SCREW, 7/16-14 X 1-1/4L
7
538-1920-00-0
1
VALVE, RELIEF, 2.5 SUCTION, VIC
538-1920-10-0
VALVE, RELIEF, 2.5 SUCTION, NPT
538-1920-20-0
VALVE, RELIEF, 2.5 SUCTION, NST
8
041-0520-00-0
1
MIV TRUNNION
9
040-9160-00-0
2
SQUARE SEAL RING 1.40" O.D.
10
142-0110-00-0
2
SQUARE SEAL RING
11
217-4003-05-0
1
1/4" CAR PLUG
12
217-0201-00-0
2
1/4 NPT SQUARE HEAD STEEL PLUG
13
102521
2
SCREW, PAN PH 8-32X.38 SS
14
097-0620-00-0
2
WASHER 1/4 LOCK STEEL + ZINC
15
610-00050
1
MIV CONTROL MODULE
16
018-1610-02-0
4
CSW HH 3/8-16 X 1.00 Z
17
007-00143-000
1
MIV ADAPTER ASSEMBLY
18
037-2110-01-0
1
SHAFT, MIV ELECTRIC
19
538-00074-000
1
MIV-E GEARBOX ASSEMBLY
538-00072-000
MIV-M GEARBOX ASSEMBLY
20
064-6350-00-0
1
PIN 1/8X7/8 MIV-E VLV DRIVE
21
018-0604-08-0
4
CSW SH 6-32 X 0.50 ZINC
22
200-1250-01-1
1
MOTOR MIV-E
23
018-0604-45-0
4
SCREW, RD SL 6-32 X 0.50 ZINC
24
044-1480-00-0
1
MIV-E VLV GEARMOTOR COVER
25
048-1080-01-0
1
MOUNTING PAD
26
200-1240-00-0
1
CIRCUIT BREAKER
27
013-1360-00-0
1
SR4-14LR WHITE WIRE
28
040-00036-000
1
O-RING, 2-036 BUNA-N
29
040-1159-00-0
1
SQUARE SEAL RING .870" O.D.
30
018-1810-22-0
2
SCREW 7/16-14 X 1.00 12-PT ZINC PL
31
097-5730-01-0
2
WASHER, FLAT M10 SS
32
105218
2
NUT, FINISHED 3/8-16 SS
33
008-0791-00-0
2
SWITCH CAP
34
040-8210-00-0
2
SEAL RING
35
064-6600-00-0
2
SWITCH PIN
36
200-2450-00-0
2
SWITCH
37
513-0270-05-0
1
HARN, MIV POWER CABLE WIRINGL (NOT SHOWN)
