2.10 Heating
Cabin heating is part of the standard equipment of the C42 / C42B / C42 UK / C42B
UK / C42E :
Figure 51: Schematic diagram of the heating system
Figure 52: Heating system elements
cold air inlet
heating hose in
the cockpit
heating valve warm air outlet
firewall
control knob
heating valve
muffler with heat
exchanger
(exhaust shroud)
heating valve
exhaust shroud
heating hose with
