Chapter 2 Product Information
- 15 -
Figure 2-3 Components of the CS200 of sheet metal housing (three-phase 380 to 480 V, 45 kW and above)
Front cover
Logo
Operation panel
Fan
Side cover
AC drive
nameplate
Grommet
Power terminals
Control board
