Inovance ISMG Series User Manual

6 Parameter Table
6
- 91 -
Function
Code
Parameter Name Setting Range Unit Default
ET Pro
CM
H17-53 VDO11 function selection 0 to 22 - 0
St Ru
-
H17-54 VDO11 logic selection
0: Output 1 when function valid
1: Output 0 when function valid
- 0
St Ru
-
H17-55 VDO12 function selection 0 to 22 - 0
St Ru
-
H17-56 VDO12 logic selection
0: Output 1 when function valid
1: Output 0 when function valid
- 0
St Ru
-
H17-57 VDO13 function selection 0 to 22 - 0
St Ru
-
H17-58 VDO13 logic selection
0: Output 1 when function valid
1: Output 0 when function valid
- 0
St Ru
-
H17-59 VDO14 function selection 0 to 22 - 0
St Ru
-
H17-60 VDO14 logic selection
0: Output 1 when function valid
1: Output 0 when function valid
- 0
St Ru
-
H17-61 VDO15 function selection 0 to 22 - 0
St Ru
-
H17-62 VDO15 logic selection
0: Output 1 when function valid
1: Output 0 when function valid
- 0
St Ru
-
H17-63 VDO16 function selection 0 to 22 - 0
St Ru
-
H17-64 VDO16 logic selection
0: Output 1 when function valid
1: Output 0 when function valid
- 0
St Ru
-
Group H30: Servo Variables Read via Communication
(Invisible on operation panel)
Function
Code
Parameter Name
Setting
Range
Unit Default ET
Pro
CM
H30-00 Servo state read by communication - - - -
Dp
PST
H30-01 DO function state 1 read via communication - - - -
Dp
PST
H30-02 DO function state 2 read via communication - - - -
Dp
PST
H30-03 Input pulse signal sampling read via communication - - - -
D
PST
Group H31: Servo Variables Set via Communication
(Invisible on operation panel)
Function
Code
Parameter Name Setting Range Unit Default
ET Pro
CM
H31-00 VDI virtual level set via communication 0 to 65535 - 0
Im Ru
PST
H31-04 DO state set via communication 0 to 31 - 0
Im Ru
PST
H31-09 Speed reference set via communication -6000.000 to 6000.000 RPM 0
Im Ru
S
H31-11 Torque reference set via communication -100.000 to 100.000 % 0
Im Ru
T
