Inovance MD380T5.5GB User Manual

MD380 User Manual Function Code Table
- 133 -
Function
Code
Parameter Name
Setting Range
Default Property
AC-24 AO1 ideal current 1 0.000–20.000 mA
Factory
corrected
☆
AC-25 AO1 sampling current 1 0.000–20.000 mA
Factory
corrected
☆
AC-26 AO1 ideal current 2 0.000–20.000 mA
Factory
corrected
☆
AC-27 AO1 sampling current 2 0.000–20.000 mA
Factory
corrected
☆
5.2 Monitoring Parameters
Function Code Parameter Name Min. Unit
Communication
Address
Group U0: Standard Monitoring Parameters
U0-00 Running frequency (Hz) 0.01 Hz 7000H
U0-01 Set frequency (Hz) 0.01 Hz 7001H
U0-02 Bus voltage 0.1 V 7002H
U0-03 Output voltage 1 V 7003H
U0-04 Output current 0.01 A 7004H
U0-05 Output power 0.1 kW 7005H
U0-06 Output torque 0.1% 7006H
U0-07 DI state 1 7007H
U0-08 DO state 1 7008H
U0-09 AI1 voltage (V) 0.01 V 7009H
U0-10 AI2 voltage (V)/current (mA) 0.01 V/0.01 mA 700AH
U0-11 AI3 voltage (V) 0.01 V 7007BH
U0-12 Count value 1 700CH
U0-13 Length value 1 700DH
U0-14 Load speed 1 700EH
U0-15 PID setting 1 700FH
U0-16 PID feedback 1 7010H
U0-17 PLC stage 1 7011H
U0-18 Input pulse frequency (Hz) 0.01 kHz 7012H
U0-19 Feedback speed 0.01 Hz 7013H
U0-20 Remaining running time 0.1 Min 7014H
U0-21 AI1 voltage before correction 0.001 V 7015H
U0-22
AI2 voltage (V)/current (mA) before
correction
0.01 V/0.01 mA 7016H

Inovance MD380T5.5GB Specifications

General

Brand	Inovance
Model	MD380T5.5GB
Category	DC Drives
Language	English
