Inovance MD380T5.5GB User Manual

Selection and Dimensions
MD380 User Manual
- 276 -
8.4 Selection of Peripheral Electrical Devices
Table 8-14 Selection of peripheral electrical devices of the MD380
AC Drive Model
MCCB
(A)
Contactor
(A)
Cable of Input
Side Main Circuit
(mm
2
)
Cable of Output
Side Main Circuit
(mm
2
)
Cable of
Control Circuit
(mm
2
)
Single-phase 220 V
MD380S0.4GB 6 9 0.75 0.75 0.5
MD380S0.7GB 10 12 0.75 0.75 0.5
MD380S1.5GB 16 18 1.5 1.5 0.5
MD380S2.2GB 25 25 2.5 2.5 0.5
Three-phase 220 V
MD380-2T0.4GB 4 9 0.75 0.75 0.5
MD380-2T0.75GB 6 9 0.75 0.75 0.5
MD380-2T1.5GB 10 12 0.75 0.75 0.5
MD380-2T2.2GB 16 18 1.5 1.5 0.5
MD380-2T3.7GB 20 25 2.5 2.5 0.75
MD380-2T5.5GB 32 32 4.0 4.0 0.75
MD380-2T7.5GB 40 40 6.0 6.0 0.75
MD380-2T11G 50 50 10 10 0.75
MD380-2T15G 63 63 16 16 0.75
MD380-2T18.5G 80 80 25 25 1.0
MD380-2T22G 100 115 35 35 1.0
MD380-2T30G 125 125 50 50 1.0
MD380-2T37G 160 185 70 70 1.0
MD380-2T45G 200 225 95 95 1.0
MD380-2T55G 225 225 120 120 10
MD380-2T75G 350 400 150 150 1.0
Three-phase 380 V
MD380T0.7GB 4 9 0.75 0.75 0.5
MD380T1.5GB 6 9 0.75 0.75 0.5
MD380T2.2GB 10 12 0.75 0.75 0.5
MD380T3.7GB 16 18 1.5 1.5 0.5
MD380T5.5 GB 20 25 2.5 2.5 0.75
MD380T7.5 GB 25 25 4.0 4.0 0.75
MD380T11 GB 32 32 6.0 6.0 0.75
MD380T15GB 40 40 6.0 6.0 0.75
MD380T18.5G 50 50 10 10 1.0
MD380T22G 50 50 10 10 1.0
MD380T30G 63 63 16 16 1.0
