MD380 User Manual Desc
ription of Function Codes
- 187 -
Function Code Parameter Name Setting Range Default
F7-09 Accumulative running time 0–65535 h -
It is used to display the accumulative running time of the AC drive. After the accumulative
running time reaches the value set in F8-17, the terminal with the digital output function 12
becomes ON.
Function Code Parameter Name Setting Range Default
F7-10 Product number AC drive product number -
F7-11 Software version Software version of control board -
F7-12
Number of decimal
places for load speed
display
0: 0 decimal place
1: 1 decimal place
2: 2 decimal places
3: 3 decimal places
1
F7-12 is used to set the number of decimal places for load speed display. The following
gives an example to explain how to calculate the load speed:
Assume that F7-06 (Load speed display coefficient) is 2.000 and F7-12 is 2 (2 decimal
places). When the running frequency of the AC drive is 40.00 Hz, the load speed is 40.00 x
2.000 = 80.00 (display of 2 decimal places).
If the AC drive is in the stop state, the load speed is the speed corresponding to the set
frequency, namely, "set load speed". If the set frequency is 50.00 Hz, the load speed in the
stop state is 50.00 x 2.000 = 100.00 (display of 2 decimal places).
Function Code Parameter Name Setting Range Default
F7-13 Accumulative power-on time 0–65535 h 0 h
It is used to display the accumulative power-on time of the AC drive since the delivery. If the
time reaches the set power-on time (F8-17), the terminal with the digital output function 24
becomes ON.
Function Code Parameter Name Setting Range Default
F7-14 Accumulative power consumption 0–65535 kWh /
It is used to display the accumulative power consumption of the AC drive until now.
Group F8: Auxiliary Functions
Function Code Parameter Name Setting Range Default
F8-00 JOG running frequency 0.00 Hz to maximum frequency 2.00 Hz
F8-01 JOG acceleration time 0.0–6500.0s 20.0s
F8-02 JOG deceleration time 0.0–6500.0s 20.0s
These parameters are used to dene the set frequency and acceleration/deceleration time
of the AC drive when jogging. The startup mode is "Direct start" (F6-00 = 0) and the stop
mode is "Decelerate to stop" (F6-10 = 0) during jogging.
