4.8 Cu. Ft. Gas Convection Range with Self Clean and Air Fry
4 Position an oven rack in the center rack position. Check the level of your range with a carpenter level using the two
positions.
5 After your range is level, make sure that the rear leg is under the anti-tip device. See Installing the anti-tip device
on
page 21.
Assembling the top burners
1 Position surface burner heads on top of the surface burner manifolds. The electrodes fit into the slots in the bottom of
the heads. Make sure that the surface burner heads are flat and parallel with the cooktop.
2 Place the matching size cap on top of each surface burner head.
3 Place the grates on the cooktop.
CAUTION: Don’t operate the surface burners without all burner parts in place.
