www.insigniaproducts.com
24
Installing the burner knobs
Your range may have a “KD Knob + handle design” that you need to install.
1 Check all five knobs.
2 Push each knob in all the way to fully attach the shaft and make sure that each knob is easy to rotate.
Installing the oven door handle
You range may have a “KD handle” that you need to install.
1 Check your installation kits for the handle and hex wrench.
2 Make sure that the side with the screw holes faces towards the oven door.
3 Place the door handle against the oven door and fit it on the connection part.
4 Use the Allen wrench to tighten both sides of the door handle.
Handle
Screw
hole
Hex wrench
