Intel S1200BTLRM Specification

Overview Intel® Server Board S1200BT TPS
Revision 1.0
Intel order number G13326-003
2
2. Overview
The Intel
®
Server Board S1200BT is a monolithic printed circuit board (PCB) with features
designed to support entry-level severs. It has two board SKUs, namely S1200BTL
and S1200BTS.
2.1 Intel
®
Server Board S1200BT Feature Set
Table 1. Intel
®
Server Board S1200BT Feature Set
Feature
Description of S1200BTL
Description of S1200BTS
Processor
Support for one Intel
®
Xeon
®
Processor E3-
1200 Series or Intel
®
Core™ Processor i3-
2100 Series in FC-LGA 1155 socket package.
 2.5 GT/s point-to-point DMI interface
to PCH
 LGA 1155 pin socket
Support for one Intel
®
Xeon
®
Processor E3-
1200 Series or Intel
®
Core™ Processor i3-
2100 Series in FC-LGA 1155 socket package.
 2.5 GT/s point-to-point DMI interface
to PCH
 LGA 1155 pin socket
Memory
Two memory channels with support for
1066/1333 MHz ECC Unbuffered (UDIMM)
DDR3.
 Up to 2 UDIMMs per channel
 32 GB max with x8 ECC UDIMM (2
Gb DRAM)
Two memory channels with support for
1066/1333 MHz ECC Unbuffered (UDIMM)
DDR3.
 Up to 2 UDIMMs per channel 32 GB
max with x8 ECC UDIMM (2 Gb
DRAM)
Chipset
Support for Intel
®
C204 Platform Controller Hub
(PCH) chipset
ServerEngines* LLC Pilot III BMC controller
(Integrated BMC)
Support for Intel
®
C202 Platform Controller
Hub (PCH) chipset
I/O
External connections:
 DB-15 video connectors
 DB-9 serial Port A connector
 Four ports on two USB/LAN combo
connectors at rear of board
Internal connections:
 Two USB 2x5 pin headers, each
supporting two USB 2.0 ports
 One 2x5 Serial Port B headers
 Two 6Gb/s SATA ports and four
3Gb/s SATA ports
 One SAS mezzanine slot for optional
SAS module
External connections:
 DB-15 video connectors
 DB-9 serial Port A connector
 Four ports on two USB/LAN combo
connectors at rear of board
Internal connections:
 Two USB 2x5 pin headers, each
supporting two USB 2.0 ports
 One 2x5 Serial Port B headers
 Six 3Gb/s SATA ports
