Dimensions and connections (models E20-E25)

(1) Return radiator

(2) Plug

(3) Radiator out

(4) Riser DHWH

(5) Heat transfer fluid in

(6) Heat transfer fluid out

(7) Electrical connections

(7)

Front

(1)

(2)

(3)

(4)

(6)

(5)

1500 mm

(1525 mm incl. feet)

®

(7)

®

539

®

®®

672

583

417

271

®

750

®®®®®

128 296 372 603 700
