51
Control unit Rego 600
If you are an installer, note that you can find certain information about the operation of the control
unit in the sections intended for the end user. It is therefore important for installers to read the entir e
guide before putting the heat pump into service.
Installer/service settings
As the installer, “Installer / Service” gives you access to all the menu displays that the end user has at
customer levels 1 and 2. Note that the menu display is connected to the selected operating mode.
You will never see displays that concern anything else but the selected operating mode.
Installer/Service menu
By holding down the “Menu” button for 10 seconds and then
enter “Menu” you will come to settings for installers or service
companies. The Menu display is divided into lines and each
display has a number to make it easy to find. You will auto-
matically return to level 1 again after 30 seconds.
Joint displays for operating modes A, B and C
Temperature settings
Heat curve
adjust. (break) 1.3
Return Select
Clock setting
Clock sett. add heat
accord. to clock 4.2
Return Select
Line 4
Line 5
Commiss./Service
Select operation
mode A B C 5.1
Return Select
Here you can “break” the heat curve up or down for each
fifth degree of outdoor temperature. You can e.g. do a
temporary increase on the curve at 0°C outdoor tempera-
ture.
You can block the additional heat totally during certain
times of day. Instructions are found in the chapter on clock
controls in the increased customer level.
Here you choose the operational mode you require. Con-
tinuous operation is the factory setting.
When controlling functions you can manually start and stop
pumps and valves etc here.
Line 1
Commiss./Service
Manual operation of
all functions 5.3
Return Select
WARNING!
Installer only. As an end-user you
must never go into this level!
Rego600 I/S
020301 12:00:00 Fr
Heat Info Menu
To Next Page
