IVT GreenlineC User Manual

63
Sensor table
The table shows the resistance of all sensors at different temperatures.
Temperature °C
k
ΩΩ
ΩΩ
Ω Temperature °C
k
ΩΩ
ΩΩ
Ω
Temperature °C
k
ΩΩ
ΩΩ
Ω
-40 154.30 5 11.900 50 1.696
-35 111.70 10 9.330 55 1.405
-30 81.70 1 5 7.370 6 0 1.170
-25 60.40 2 0 5.870 6 5 0.980
-20 45.10 2 5 4.700 7 0 0.824
-15 33.95 3 0 3.790 7 5 0.696
-10 25.80 3 5 3.070 8 0 0.590
-5 19.77 4 0 2.510 8 5 0.503
0 15.28 45 2.055 90 0.430
Technical spec.
Model
C4 C5/D5/E5 C7/D7/E7 C9/D9/E9 D11/E11
Emitted /Supplied output at 0/35°C
1
kW
4.0/1.0 5.6/1.3 7.7/1.7 8.6/1.9 11.2/2.6
Emitted /Supplied output at 0/50°C
1
kW
3.3/1.1 4.8/1.5 6.6/2.0 8.2/2.8 10.9/3.8
Nominal flow heating medium
l/s
0.13 0.18 0.26 0.29 0.38
Nominal flow cooling medium
l/s
0.22 0.31 0.46 0.50 0.64
Permitted ext. pressure drop heating medium
kPa
28 24 21 25 25
Permitted ext. pressure drop cooling medium
kPa
32 47 41 45 79
Max pressure radiator system
bar 1,5
Max pressure cooling medium system
bar 4
Highest outgoing heating medium temp.
C 55
Operating temperature heat transfer system
C -5 to +20
Integrated heat / HTF pump
Yes
Electrical connection
400V, N3-phase
Add. heat reconnectable C/E-model
kW 3.0 / 6.0 / 9.0
Fuse sizeD-model
AT - 10
Fuse size C/E-model. Depends on electrical
additional heat
Electric water heater 6 kW
Electric water heater 9 kW
Electric element 15.75
AT
AT
AT
16
20
-
16
20
-
16
20
-
20
25
-
20
25
-
Compressor
Piston Scroll
Refrigerant R407C
kg 1,0 1,2 1,3 1,4 1,6
Connection, heating medium
Cu/DN 22
Connection cooling medium
Cu/DN 28
Dimensions D/E-model (WxDXH)
mm - 600x450x600
Weight D/E-model
kg - 160 180
Dimensions C-model (WxDXH)
mm 600x600x1770 -
Weight C-model
Copper/Stainless hw-cylinder
kg 180/150 220/190 -
Integrated double-shelled hw-cylinder on
C-models Copper or stainless*
Yes -
Domestic hot water C-model
litres 165 -
Control unit
Rego 600
1 Output data at 0/35°C and 0/50°C are stated in accordance with the European standard EN 255. Additional heat is not included.
* Anode included with C-models with stainless hw-cylinder.
