S5 Workshop Manual Engine
2. Dismantling
1) Dismantle condenser housing.
2) Dismantle fan motor and temperature switch connector.
3) Dismantle air hose.
4) Dismantle condenser assembly.
5) Dismantle fan motor assembly.
6) Dismantle condenser support.
3. Inspection
1) Air temperature switch
Put the sensor into the water.
Heat the water and inspect whether it is conducted.
Condenser fan motor
At speed of ≤ 60 Km/h and intake temperature of ≥ 50 °C, inspect working condition
of the fan.
5. Air Filter
1. Component
