S5
Workshop Manual
Engine
EM
-9
St
ructure Parameter o
f
Engine:
Structure Parameter Table o
f
Engine
Model
HFC4GA3.1D
Type
L4/16.
DOHC
.MPI
Cylinder number
4
Fuel chamber
Pentroof type
Total displacement (
CC
)
1997
Cylinder bore
mm
85
.0
Stroke
mm
88
.0
Compression ratio
8.5
Valves and drive mechanism
DOHC
-4
Cylinder distance
mm
93
Cylinder body height
mm
235
Big and small center distance of connecting rod
150
Valve
Number
Air intake valve
8
Air exhaust valve
8
Output
Max. power
130
kW
/ 5200 rpm
Max
.torque
235
N•m
/ 2000-4000 rpm
Fuel octane value
RON93# and above 93# grade of lead-free
gasoline
It meets emission laws and rules.
State V
Overall dimensions
Length 692 mm× width 675 mm× height 704
mm
Engine weight (
Kg
)
(Dry condition)
Lubrication system
Pressure oil supply
Fuel supply way
Electric fuel pump, without oil return system
Oil pump type
Cycloid gear pump
Cooling system
Forced circular water cooling
Water pump type
Centrifugal, impeller type
www.cargeek.ir
www.cargeek.ir
www.CarGeek.ir
8
10
Table of Contents
Precautions
1
Parts to be Tightened According to the Specified Angle
2
Dismantling Sealant
2
Special Tool Table
4
Preparation Work
4
Auxiliary Material Table of Engine Assembly
7
Auxiliary Material Table for Cylinder Head Assembly
7
Structure Overview of Engine
8
Structure Parameter Table of Engine
9
Engine No. Position
10
Drive Belt Diagram
10
Dismantling
11
Air Filter and Air Pipe
12
Inspection and Replacement of Air Filter Element
13
Engine Cylinder Block
14
Camshaft
17
Rocker Arm Inspection
18
Camshaft Inspection
18
Camshaft Installation
19
Tightening Torque
20
Connecting Rod Dismantling
22
Piston and Piston Pin Inspection
24
Piston Ring Inspection
25
Connecting Rod Installation
25
Crankshaft
28
Crankshaft Dismantling
29
Crankshaft Inspection
29
How to Use Plastic Gauge
30
Inspection of Air Exhaust System
33
Exhaust Pipe
33
Turbocharger
35
Air Intake Manifold
36
Intercooler
39
Air Filter
40
Cylinder Head Cover Assembly
42
Valve Spring
45
Valve Guide Pipe
45
Replacement of Valve Race
46
Replace Valve Guide Pipe
46
Valve Guide Pipe Enlarged Dimensions
47
Timing Belt
49
Chain Wheel, Tensioner Belt Pulley and Idler Wheel Inspection
52
Auto-Tensioner Inspection
52
Timing Belt Inspection
53
Crankshaft Installation
56
Install Automatic Tensioner
59
Install Tensioning Wheel Onto Tensioning Rod
59
Fault Diagnosis
62
Engine Is Difficult to Start
62
Power Is Insufficient During Running
62
Knock Cylinder Sound in the Engine
62
Engine too Hot
63
Oil Consumption Is too Much
63
Maintenance Data and Specification
64
Engine Overhaul Data List
64
Fastening Torque Specification Table
68
