Jackson 10 Series User Manual

07610-002-41-09-F
59
VACUUM BREAKER/CONNECTOR ASSEMBLIES
PARTS
Outlet Connector
5700-002-61-19
Complete Vacuum Breaker Assembly, Standard
5700-002-61-18
Complete Vacuum Breaker Assembly, 4SH
5700-002-44-79
Complete Vacuum Breaker Assembly, 5HH
5700-002-61-66
Plated Outlet Assembly, Standard
5700-002-61-21
Plated Outlet Assembly, 4SH
5700-002-61-69
Plated Outlet Assembly, 5HH
5700-002-61-68
Outlet Connector
5700-002-61-19
Plated Inlet Assembly, Standard
5700-002-61-20
Plated Inlet Assembly, 4SH
5700-002-61-70
Plated Inlet Assembly, 5HH
5700-002-61-67
Adapter, 3/4” CU to MSPS
4730-411-11-01
Bushing, 3/4” to 1/2” Reducer
4730-402-11-01
Copper Tube, 1/2” x 8”
5700-001-04-65
Union, Female Half
5700-002-61-85
MODEL 10A ASSEMBLIES
