Jackson 10 Series User Manual

07610-002-41-09-F
1
SPECIFICATIONS
21”
18”
19 1/4”
15 1/4”
10U
24 1/4”
5” HH
2 3/4”
14 1/2” 11”
D
20 1/4”
4” SH
29 1/4”
5” HH
14” TO
INLET
5” 4” SH
ONLY
A
B
13 1/2”
LEFT VIEW
E
22 1/4”
34”
11 1/2”
4” SH
19”
25”
4” SH
CIRCUIT
BREAKER
C
27 1/2”
16 1/2
13”5 1/4”
C
9”
14 7/8”
TO THE
WALL
1 13/16”
B
FRONT VIEW
16 1/2
B
4”
28 3/4”
TOP VIEW
LEGEND
A - Water inlet 1/2” NPT. Plumbing can be directed either
left or right.
B - Drain connection 1 1/2” NPT
C - Electrical connection
D - Clearance for dishes:
10” (10A 4” shorter hood)
14” (10A standard hood)
19” (10A 5” higher hood)
E - Machine height:
45 1/2” (9” shorter leg, 4” shorter hood)
58 1/4” (standard leg and hood)
63 1/4” (standard leg, 5” higher hood)
All dimensions in inches.
All vertical dimensions are +/- 1/2” from the fl oor due to
the adjustable bullet feet.
10A MACHINE DIMENSIONS
