Jackson TempStar Series User Manual

3
07610-002-23-32-AC
25 [637mm]
73 1/4 [1873mm]
34 [861mm]
27 [686mm]
25 1/4 [641mm]
3 [76mm]
1 [25mm]
11 3/4 [298mm]
15 1/4 [387mm]
73 [1856mm]
86 3/4 [2203mm]
17 [432mm]
4 [102mm]
4 [102mm]
A
B
B
B
C
LEGEND
A - Drain 1 1/2" NPT
B - Water Inlet 3/4" NPT
C - Electrical Connection
All dimensions from the oor can be
increased 2" using the machine's
adjustable feet.
DIMENSIONS - PRESSURE REGULATOR OPTION
SPECIFICATIONS

Jackson TempStar Series Specifications

General

Brand	Jackson
Model	TempStar Series
Category	Dishwasher
Language	English
