Jackson TempStar Series User Manual

9
07610-002-23-32-AC
Volts Phase Freq
Rinse Heater
Ratings
Total Amps
Typical Electrical
Circuit
208 1 60 Hz N/A 12 A 15 A
230 1 60 Hz N/A 12 A 15 A
208 3 60 Hz N/A 12 A 15 A
230 3 60 Hz N/A 12 A 15 A
Volts Phase Freq
Rinse Heater
Ratings
Total Amps
Typical Electrical
Circuit
415 3 60 Hz 12 kW 28 A 35 A
415 3 60 Hz 14 kW 30 A 40 A
208 1 60 Hz 12 kW@240 V 75 A 100 A
208 1 60 Hz 14 kW@240 V 82 A 110 A
230 1 60 Hz 12 kW@240 V 81 A 110 A
230 1 60 Hz 14 kW@240 V 90 A 125 A
208 3 60 Hz 12 kW@240 V 48 A 60 A
208 3 60 Hz 14 kW@240 V 52 A 70 A
230 3 60 Hz 12 kW@240 V 52 A 70 A
230 3 60 Hz 14 kW@240 V 57 A 80 A
460 3 60 Hz 12 kW@480 V 24 A 30 A
460 3 60 Hz 14 kW@480 V 26 A 35 A
TEMPSTAR HH & HH-E:
Volts Phase Freq
Rinse Heater
Ratings
Total Amps
Typical Electrical
Circuit
208 1 60 Hz N/A 31 A 35 A
230 1 60 Hz N/A 33 A 35 A
208 3 60 Hz N/A 23 A 25 A
230 3 60 Hz N/A 24 A 35 A
460 3 60 Hz N/A 10 A 15 A
TEMPSTAR HH NB & TEMPSTAR HH LT:
TEMPSTAR HH S:
Volts Phase Freq
Rinse Heater
Ratings
Total Amps
Typical Electrical
Circuit
208 1 60 Hz 15.4 kW 87 A 110 A
230 1 60 Hz 15.4 kW 96 A 125 A
208 3 60 Hz 15.4 kW 55 A 70 A
230 3 60 Hz 15.4 kW 61 A 80 A
460 3 60 Hz 15.4 kW 28 A 35 A
TEMPSTAR HH VENTLESS:
Local codes may require more stringent protection than what is displayed here. Always verify with your electrical service
contractor that your circuit protection is adequate and meets all applicable national and local codes. Numbers in this manual
are for reference and may change without notice.
Typical Electrical Circuit is based on:
1. 125% of the full amperage load of the machine.
2. Typical xed-trip circuit breaker sizes as listed in the NEC (latest edition).
NOTICE
i
ELECTRICAL REQUIREMENTS
SPECIFICATIONS
