Jackson TempStar Series User Manual

07610-002-23-32-AC
66
The models covered in this manual come supplied with various wash motor assemblies, depending on the characteristics
of the machine. To ensure that the correct wash motor assembly is ordered for the model being serviced, refer to the
following table:
MODEL VOLTS Hz PHASE
WASH MOTOR
ASSEMBLY
Tempstar HH 415 50 3 06105-002-01-29
Tempstar HH, HH NB, HH S, HH LT 208 60 1 06105-002-01-29
Tempstar HH, HH NB, HH S, HH LT 230 60 1 06105-002-01-29
Tempstar HH, HH NB, HH S, HH LT 208 60 3 06105-002-01-29
Tempstar HH, HH NB, HH S, HH LT 230 60 3 06105-002-01-29
Tempstar HH, HH NB, HH S, HH LT 460 60 3 06105-002-09-30
When servicing a wash motor please refer to the wiring schematic found on the motor to ensure that it is wired
correctly. Different manufacturers use different wire color codes and your new motor might not connect using
the same wires. Always refer to the diagrams on the motor you are installing. If the schematics have been
removed from the motor you are installing, contact the manufacturer immediately.
The dishmachines covered in this manual come supplied with various heaters, depending on the characteristics of the
machine. To ensure that the correct heater is ordered for the model being serviced, refer to the following table:
MODEL V Hz PH
WASH HEATER
ASSEMBLY
40°F RISE
RINSE HEATER
(12 kW)
70°F RISE
RINSE HEATER
(14 kW)
Tempstar HH 415 50 3 04540-002-43-09 04540-002-43-10 N/A
Tempstar HH 208 60 1 04540-121-47-39 04540-121-47-40 04540-121-63-38
Tempstar HH 230 60 1 04540-121-47-39 04540-121-47-40 04540-121-63-38
Tempstar HH 208 60 3 04540-121-47-39 04540-121-47-40 04540-121-63-38
Tempstar HH 230 60 3 04540-121-47-39 04540-121-47-40 04540-121-63-38
Tempstar HH 460 60 3 04540-121-65-99 04540-100-01-15 04540-121-63-39
Tempstar HH NB, HH LT 208 60 1 04540-121-47-39 N/A N/A
Tempstar HH NB, HH LT 230 60 1 04540-121-47-39 N/A N/A
Tempstar HH NB, HH LT 208 60 3 04540-121-47-39 N/A N/A
Tempstar HH NB, HH LT 230 60 3 04540-121-47-39 N/A N/A
Tempstar HH NB, HH LT 460 60 3 04540-121-65-99 N/A N/A
Tempstar HH S 208 60 1 04540-121-47-39 N/A N/A
Tempstar HH S 230 60 1 04540-121-47-39 N/A N/A
Tempstar HH S 208 60 3 04540-121-47-39 N/A N/A
Tempstar HH S 230 60 3 04540-121-47-39 N/A N/A
Tempstar HH S 460 60 3 04540-121-65-99 N/A N/A
MOTORS & HEATERS
PARTS
NOTICE
