116
A
B
P
G
T
A
B
P
T
.5 ci .5 ci .5 ci
3625 psi
3625 psi
Supply
.036
Drain
.031
285 psi
2.81 ci
Displacement
Control
Tow
Valve
Reverse
Diag.
Forward
Diag
3000
RPM
A
B
Traction
Pump
Gear
Pump
Rear
Reel
Valve
G
Front
Reel
Valve
1167
psi
1167
psi
LR Reel Motor
RR Reel Motor
*
*
1167
psi
LF Reel Motor
*
1167
psi
C Reel Motor
*
1167
psi
RF Reel Motor
*
Reel
Diag.
Reel
Diag.
Strg.
Diag.
10
Micron
25 psi
Crack
Bypass
30 psi
Crack
Bypass
100
Mesh
Screen
Return
Filter
Oil
Cooler
A
B
B
D
E
F
G
H
J
* Reel Motor Displacement
LF-3400 .72 ci
LF-3800 1.01 ci
LF 3400 / LF 3800
58.1 Hydraulic Schematic
5 Gang Units (LF 3400, LF 3800 and LF 3400 Turbo)
Serial No. All
LF34-37
