LF 3400/ LF 3800
39.1 Five Inch Reel Assembly
LF 3400, LF 3400 Turbo and LF 4675 Models
Serial No. All
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
2
3
36
37
LF-3400 Units with single point Flash Attach
Serial Number 67868 1601 ~ 1758
Serial Number 67869 1601 ~ 1704
Your machine was built before the two point Flash Attach (Shown Above) was introduced. To
update your tractor and cutting units, Order Flash Attach Re-Work Kit Part No. 5003735
Note: The update kit will update only one cutting unit and reel motor. Five kits will be required
to update all five cutting units.
Single Point
Flash Attach
