96
> Change from previous revision
LF 3400 / LF 3800
43.1 Down Pressure Spring
Serial No. All
Item Part No. Qty. Description Serial Numbers/Notes
1
461397 1 Roll Pin, 1/4 x 1-1/4”
2 453017 1 Flat Washer, 1/2
3 400268 1 Screw, 3/8-16 x 1-3/4” Hex Head
4 3008593 1 Tube, Down Pressure
5 460312 1 Hairpin
6 443110 1 Nut, 3/8-16 Hex
7 311870 1 Spring, Compression
8 366974 1 Rod End
9 446142 1 Lockwasher, 3/8 Heavy
10 352435 1 Spacer
11 443812 1 Nut, 3/8-24 Hex
1
2
3
4
5
6
7
8
9
10
11
