2 SPECIFICATIONS
6
2 SPECIFICATIONS
2.1 PRODUCT IDENTIFICATION_________________________________________________
67866.............................. LF 3800, 5 Gang 2WD, uses 7”
(178 mm) diameter reel
67867.............................. LF 3800, 5 Gang 4WD, uses 7”
(178 mm) diameter reel
67868.............................. LF 3400, 5 Gang 2WD, uses 5”
(127 mm) diameter reel
67869.............................. LF 3400, 5 Gang 4WD, uses 5”
(127 mm) diameter reel
67889.............................. LF 3400 Turbo, 5 Gang 4WD, uses
5” (127 mm) diameter reel
67915.............................. LF 4675 Turbo, 7Gang 4WD, uses
5” (127 mm) diameter reel
67916.............................. LF 4677 Turbo, 7 Gang 4WD, uses
7” (178 mm) diameter reel
67936.............................. LF 3800 Turbo, 5 Gang 4WD, uses
7” (178 mm) diameter reel
Serial Number ................ An identification plate, like the one
shown, listing the serial number, is
attached to the frame of the
tractor and is located on the
operator’s right just over the rear
axle.
Always provide the serial number of the unit when ordering
replacement parts or requesting service information.
2.2 V1305-E ENGINE __________________________________________________________
Make ............................... Kubota
Model .............................. V1305E Diesel, 4 cycle, Liquid
Cooled
Horsepower .................... 33.5 Hp (25 kW) @ 3000 rpm
Displacement .................. 81.5 in
3
(1335 cm
3
)
Torque ............................ 63 ft. lbs. (85.4 Nm) @ 2500 rpm
Fuel:
Type.......................... No. 2 Diesel
Rating ....................... Min. cetane rating 45
Capacity.................... 17 U.S. gal. (64.3 liters)
Governor Setting:
High Idle ................... 3150 rpm
Low Idle .................... 1200 rpm
Lubrication:
Capacity.................... 5.5 U.S. qts.(5.2 liter)
Type.......................... SAE 10W30
API Classification ..... CD/CE
Air Filter .......................... Donaldson, dry type with
evacuator valve and service
indicator.
Alternator ........................ 40 Amp
2.3 V1505-E ENGINE __________________________________________________________
Make ............................... Kubota
Model .............................. V1505E Diesel, 4 cycle, Liquid
Cooled
Horsepower .................... 37.5 Hp (28 Kw) @ 3000 rpm
Displacement .................. 91.4 in.
3
(1498 cm
3
)
Torque ............................ 73 ft. lbs. (99 Nm) @ 2100 rpm
Fuel:
Type.......................... No. 2 Diesel
Rating ....................... Min. cetane rating 45
Capacity.................... 17 U.S gal. (64.3 liters)
Governor Setting:
High Idle.................... 3150 rpm
Low Idle .................... 1200 rpm
Lubrication:
Capacity.................... 5.5 U.S. qts. (5.2 liter)
Type.......................... SAE 10W30
API Classification...... CD/CE
Air Filter .......................... Donaldson, dry type with
evacuator valve and service
indicator.
Alternator ........................ 40 Amp
Product
EEC Sound
Power
Sound Pressure
Level Operator Ear
Vibration M/S
2
Arms Body
67866 99 dba 83.4 dba .924 .011
67867 99 dba 83.4 dba .924 .011
67868 100 dba 81.9 dba .629 .0928
67869 100 dba 81.9 dba .629 .0928
RACINE, WI
MADE IN U.S.A.
TEXTRON TURF CARE AND SPECIALTY PRODUCTS
67866 1601
