Page 37
11.0 Programming Instructions
11.1 Programming Filter/Circulation Pump Run Time
CYCLE
screen display “Circ”.
changes:
• Press the SELECT button once. The previously programmed
start time appears on the LCD display.
• Press WARMER or COOLER
start time in 30-minute increments.
• Press the SELECT buttons to program duration.
• Press WARMER or COOLER buttons to program
the duration time in 1 hour increments.
• Press DISPLAY button to save changes and recall the main
water temperature display. Note: If no button is pressed within 30
seconds, all changes are recorded and the screen automatically
returns to the standard water temperature display.
Note: when the standard mode is selected (sec. 10.3, page 36), the lter/
circulation pump automatically turns on for a heat call regardless of the
pump’s programmed start time and duration.
11.2 Programming Filter Cycles
circulation pump. These cycles are factory programmed to start at 6:00
am, 12:00 (noon), 6:00 p.m., and 12:00 (Midnight). The control system
time of day at which it begins; 2) the duration of the cycle.
Note: When “Standard” mode is selected (sec. 10.3, page 36) and the
lter/circulation pump is set to the factory default duration of 24-hours
(sec. 11.1), each cycle is displayed on the main control panel, when
