Page 54
17.0 Export 50Hz J-460/J-465/J-470/J-480
Wiring Diagram
SENSORS LCD PANEL
230 VAC, 20A / 30A / 40A, 1-Phase, 50 Hz;
USE MIN. 10mm
2
(6 AWG) COPPER CONDUCTORS ONLY
J8 J6 J7
J3
OPTIONS
FLOW SWITCH
HI - LIMIT / FREEZE SENSOR
TRANSFORMER
T1
TB3
TB3 TB4
G
11
11 2
TB2
2 1
1
2
PUMP 1
PUMP 2
HI
HI
TEMPERATURE
SENSOR
TB7
From TB1
Terminal Block
TB1
UV or CD
Ozonator
(Optional)
Circulation
Pump
TB1
2
1
TB5
1 2 3
F1
20A,
250V
SC-20
BLU (N)
BLU (N)
GRN/YEL (GND)
N N N
N
L N
N
L L L
L
L
BRN (L)
BRN (L)
L
L
N
N
Red
Black
B B Y Y
J4
STEREO
(Optional)
Power Supply (Optional)
12VAC Output to
Waterfall Light/
Footwell Light
Controller
To Heater
Relay
Z
Y
Y
Z
LED
Lighting
Controller
MAIN LCD CONTROL
PANEL
Heater
2.7 kW
1
3
5
7
9
1
3
5
7
9
11
13
JP19
JP20
JP9
1
3
5
7
9
1
3
5
7
9
11
13
JP19
JP20
JP9
Caution:
always
remove
power to
spa before
changes on
the circuit
board.
Circuit Board Jumper Settings:
JP20-1: Not Used
JP19-1: On C°, Off F°
JP19-3: On 50Hz, Off 60Hz
JP19-5: On enables Multi-Colored
LED light kit
JP19-7: Not Used
JP19-9: Not Used
JP9-1: Not Used
JP9-3: Not Used
JP9-5: Not Used
JP9-7: On enables 40A Logic
JP9-9: On 2-Pump Logic, Off 1-
Pump Logic
JP9-11: On enables 20A Logic, Off
enables 30A or 40A Logic
JP9-13: Not used
