9.8 J-470 Massage/Waterfall Selector Diagram
98
F
4:05 PM
1a
1b
2b
2b
2a
2a
1
b
a
3
3
5
5 5
55
2
4
4
b
a
Massage Selectors (1-2)
• Massageselector1divertsjetspumpNº1outputbetweenjetgroups
1a-1b.
• Massageselector2divertsjetspumpNº2outputbetweenjetgroups
2a-2b.
Waterfall Selector (3)
• Waterfallselector3controlscirculationpumpoutputtowaterfalls.
Mass Aspiration Jet Flow Control Valve (4)
• Valve(4)controlsoutputtofootwellIXJet.
Jets Without Massage Selector Controls (5)
• Jets(5)arealwaysonwhenjetspumpNº1isrunning.
