Janome MB-4 Instruction Book

11
Installing the Hoop Supporter
z Loosen the two thumbscrews on the hoop
supporter.
q Hoop supporter
w Thumbscrew
x Turn the power switch on to move the carriage to
the center.
Hold the hoop supporter with both hands and
place it under the carriage plate by
inserting the necks of both thumbscrews into the
slots in the carriage plate.
e Slot in the carriage plate
c Tighten the thumbscrews with the screwdriver to
secure the hoop supporter.
q
w
e
w
z
x
c
w

Janome MB-4 Specifications

General

Type	Embroidery machine
Number of Needles	4
USB Port	Yes
LCD Screen	Yes
Memory	Yes
Connectivity	USB
Automatic Thread Cutter	Yes
Display	LCD
