3 - 2
Section 3 Routine Maintenance
9803/7130
Section 3
3 - 2
Issue 1
Service Schedules
Pre-start Cold Checks Operation 10 50 †100 500 1000 2000
Service Points and Fluid Levels Hr Hr Hr Hr Hr Hr
HYDRAULICS
Oil Filter - Change "" ""
Oil Level ) - Check """ " "
Oil - Sample/Change "
Suction Strainer - Clean "
Hydraulic System for Leaks (Hoses etc.) - Check """"
Rod/Rams - Condition - Check """
ELECTRICS
Battery Electrolyte Level - Check "" ""
Wiring for Chafing - Check "" " " "
Battery Terminals for Condition and Tightness - Check "" " " "
BRAKES
Brake System Fluid Level - Check
""" " " "
Brake System Fluid ! - Change
"
Parking Brake - Check and Adjust
"" ""
BODYWORK AND FRAMEWORK
All Pivot Points - Grease/Check """ " " "
All Mounting Bolts for Tightness ! - Check "" ""
All Hinges - Lubricate "" ""
All Cables - Lubricate "" ""
All Slides/Control Levers - Lubricate "" ""
Extradig Dipper Wear Pads - Check and Grease "" " " "
CAB
ROPS/FOPS - Check ""
Heater Filter - Clean (if fitted) """
Windscreen Washer Fluid Level - Check """ " " "
ATTACHMENTS
Optional Equipment (as required) - Check "" " " "
Functional Test Operation 10 50 †100 500 1000 2000
and Final Inspection Hr Hr Hr Hr Hr Hr
ENGINE
Idle Speed ! - Check and Adjust "" ""
Stall Speed ! - Check Pull Down "" ""
Max. No Load Speed ! - Check and Adjust """
Exhaust System Security ! - Check "" ""
Air Inlet System Security - Check "" ""
Fuel System for Leaks and Contamination - Check "" " " "
Coolant System for Leaks and Contamination - Check "" ""
Throttle System and Control Cable ! - Check "" ""
Exhaust Smoke (excessive) - Check "" " " "
TRANSMISSION AND AXLES AND
STEERING
Torque Converter Mainline Pressure ! - Check "" ""
Clutch Pack Pressure ! - Check "" ""
Forward/Reverse - Selection/Operation - Check "" ""
Oil Cooler and Pipework - Check "" ""
To Next Page
