Cavity Blade Fuse Description
F51 7.5 Amp Brown Electronic Climate Control, Occupant Classification, Rear View
Camera, Climate Control, Headlamp Leveling, Terrain Select,
Heated Rear Window, Trailer Tow, Haptic Lane Departure
F53 7.5 Amp Brown Keyless Ignition Node Module, Electric Park Brake, RF Hub,
Cluster
F94 15 Amp Blue ECC (HVAC) Blower, Lumbar Adjust Driver Seat, Power Outlets
Rear Cargo Fuse/Relay Distribution Unit
To access the fuses, remove the access door from the left
rear panel of the rear cargo area.
The fuses may be contained in two units. Fuse holder No.
1 is located closest to the rear of the vehicle and fuse holder
No. 2 (if equipped with trailer towing) is located closest to
the front of the vehicle.
Rear Cargo Fuse Cavities
1 — Fuse Holder No. 1
2 — Fuse Holder No. 2
324 IN CASE OF EMERGENCY
