Jetmaster 18f User Manual

Releasing the door pin
Take care not to damage the door seal.
Place the door on a soft surface in a safe position to protect the glass, paint and inner seal.
Particular attention should be given so that the painted edges do not become damaged.
Retthedoorusingthereverseprocess.
Lower door pin on stove body Upper door pin attached to door
Tertiary Air Tubes
Therearetwotertiaryairtubeslocatedattheinnertopofthestovetobringairintothere.Oneislargeandone
is small. Each tube is held in its position by a swing cam catch attached with a single 8mm bolt to the left hand
innersideoftherebox.Thecamcatchhasalocatoratitsendthatlocatesinaholeattheendofthetube.When
the cam catch locator is positioned in the tube hole the bolt is tightened to hold it in this position thus trapping
the tube. This ensures that the tube will not slide out and it keeps the tube with its tertiary air ports in the correct
position within the stove.
Abovethetwotubesare2setsofbafeboards.Thetwolowerbafesareloose,justrestingonthetubesand
touchingtherearofthestove.Theyarenotxedwithanyxings.Theoneupperbafeisheldinplacebya
bracket at the rear and a bracket at the front top, being trapped between the two brackets.
Upperbafeboardandlocationbrackets
TertiaryAirTubeRemovalandLowerBafeRemoval
Thesequenceforeasyremovaloftheairtubesandlowerbafesarethus:
Firstremovethefronttertiaryairtubeclosesttothedoorofthere.
To remove the tube, slacken the 8mm bolt using the 13mm spanner provided. Once the bolt is slack then the
cam catch can be rotated slightly so that the locator comes away from the tube hole releasing the tube.
13
