– 47 –
1. Extreme backward position
When the moving knife moves at the maximum, its position is where
its front tip is withdrawn by 2.5 to 3mm from the needle center. (Other
than 9000A-SH)
(3 to 3.5mm for 9000A-SH)
2. Initial position
Coincidence of the moving knife outer periphery with the V-groove
engraved marker line on the knife-mounting base
<When the amount of withdrawal is
large>
o It becomes impossible to scoop
the needle thread or the bobbin
thread at the time of thread
trimming.
<When the amount of withdrawal is
small>
o Interference between the feed dog
and the moving knife
Adjustment Procedure Results of Improper Adjustment
Specification Max. amount of withdrawal
Other than 9000A-SH 2.5 to 3mm
9000A-SH 3 to 3.5mm
To Next Page
