– 86 –
5. Screws for attachment and positions of external parts
219.5
M4 Depth 4
2XM4 Depth 4
13.5
Ruler seat
40035589
2.4
61
149
M4 Depth 4
62.5
M5 Depth 10
M8 Depth 9
80
156
M5 Depth 4
2X3
M5 Depth 8
8.5
139.7
82
2Xø10
Standard Adjustment
