JUKI DNU-1541S User Manual

SPECIFICATIONS
Model DNU-1541 DNU-1541S DNU-1541H
Sewing speed
Max. 2,500 sti/min
See “20. SEWING SPEED TABLE” on page 39.
Max. 2,000 sti/min
See “20. SEWING SPEED TABLE” on page 39.
Stitch length (max.) Normal feed : 9 mm Reverse feed : 9 mm
Needle GROZ-BECKERT 135
×
17 (Nm 125 to Nm 180) (Standard : Nm 160)
Thread #30 to #5 (US : #46 to #138, Europe : 20/3 to 60/3)
Hook
Horizontal-axis 2.0-fold capacity hook
Lift of presser foot Hand lifter lever : 9 mm Knee lifter : 16 mm
Safety device for hook Provided as standard
Lubricating oil JUKI New Defrix Oil No. 2
Noise
• DNU-1541
- Equivalent continuous emission sound pressure level (L
pA
) at the workstation :
A-weighted value of 86.5 dB; (Includes K pA = 2.5 dB); according to ISO 10821- C.6.2 -ISO 11204 GR2 at 2,500 sti/min.
- Sound power level (LWA) ;
A-weighted value of 93.5 dB; (Includes K
WA
= 2.5 dB); according to ISO 10821- C.6.2 -ISO 3744 GR2 at 2,500 sti/min.
• DNU-1541S
- Equivalent continuous emission sound pressure level (L
pA
) at the workstation :
A-weighted value of 89.5 dB; (Includes K pA = 2.5 dB); according to ISO 10821- C.6.2 -ISO 11204 GR2 at 2,500 sti/min.
- Sound power level (L
WA
) ;
A-weighted value of 96.0 dB; (Includes K
WA
= 2.5 dB); according to ISO 10821- C.6.2 -ISO 3744 GR2 at 2,500 sti/min.
• DNU-1541H
- Equivalent continuous emission sound pressure level (LpA) at the workstation :
A-weighted value of 86.5 dB; (Includes K pA = 2.5 dB); according to ISO 10821- C.6.2 -ISO 11204 GR2 at 2,000 sti/min.
- Sound power level (L
WA
) ;
A-weighted value of 93.5 dB; (Includes K
WA
= 2.5 dB); according to ISO 10821- C.6.2 -ISO 3744 GR2 at 2,000 sti/min.
– 4 –

JUKI DNU-1541S Specifications

General

Machine Type	Single Needle Lockstitch
Max Stitch Length	9 mm
Presser Foot Lift by Hand	9 mm
Presser Foot Lift by Knee	16 mm
Lubrication	Automatic
Max Sewing Speed	2500 stitches per minute
Hook	Full Rotary Hook
Bed Size	477mm(L)×177mm(W)
