JUKI HZL-X Series User Manual

– 22 –
6-12 Vertical position of the needle threading hook
○
Remove the face cover.
Adjustmentprocedure
 1.AssembleahouseholdHA×1needle#11intotheneedlebar.
 2.Turnthehandwheeltobringtheneedlebarnearitshighestdeadpointandstopthehandwheelwhenthe
needlebarreachesthelocationwherethesetscrewintheneedlebarguideisvisible.
3. Lower the threading lever to its lowest dead point. Check whether a clearance of 0 to 0.1 mm is provided
betweenthetopendoftheneedlethreadinghookandtheupperendoftheneedleeye.(Iftheclearanceis
not0to0.1mm,theneedlemaynotbethreadeddependingonthesizeoftheneedleused.)
 4.Fitahexagonalwrenchontheneedlebarguidesetscrewtoloosenitslightly.
  •Iftheneedlethreadinghookpositionistoolow→Movetheneedlebarguideupwardandtemporarily
tighten the setscrew.
  •Iftheneedlethreadinghookpositionistoohigh→Movetheneedlebarguidedownwardandtemporarily
tighten the setscrew.
  Adjusttheneedlethreadinghookcarefully,checkingitspositionwithrespecttotheneedleeye.
  Whentheneedlethreadinghookentersandexitsfromtheneedleeye,theneedleshouldneverbebentby
the hook.
  Iftheneedlethreadinghookpositiondeviatestotherightorleft,correctthebendintheneedlethreading
hook with the tip of a thin screwdriver or change the needle threading hook with a new one.
5. When the needle threading hook is correctly positioned, fully tighten the setscrew.
Needle bar guide
setscrew
0 to 0.1 mm
