JUKI LK-1901A User Manual

79
No. Item Setting range Edit unit Initial display
Diameter of needle hole guide at the
time of thread trimming jump feed
control
1.6 to 4.0mm 0.2mm 1.6mm
Selection of prohibition of thread trimmer device control
：
Normal
：
Prohibited
― ― Normal
Magnet wiper ON output time
10 to 500ms 10ms 50ms
Magnet wiper OFF delay time 10 to 500ms 10ms 100ms
Wiper output timing selection at the time of UP dead
point stop
：
UP position
：
UP dead point position
― ― UP position
Range of move limit in + X direction -20 to 20mm 1mm 20mm
Range of move limit in -X direction
-20 to 20mm 1mm -20mm
Range of move limit in +Y direction
-20 to 10mm 1mm 10mm
Range of move limit in -Y direction -20 to 10mm 1mm
-20mm
In case of
LK1901/LK1903,
the initial display
is -10mm.
X/Y jump feed speed is set
100 to
4,000pps
10pps 2,000pps
X/Y feed forward/backward speed is
set.
100 to
4,000pps
10pps 500pps
