52
－
No. Function Setting range
State when
delivered
Remarks
U036
Feed timing is selected
When stitches are not well-tightened, set the value in
"–" direction.
−1 to 8 5
Setting on excessive "–"
side may cause needle
breakage. Be careful
when sewing heavy-
weight material.
U037
State of work clamp foot after completion of sewing can be selected
: Work clamp foot goes up after moving at the sewing start
:
Work clamp foot goes up immediately after the end of sewing.
: Work clamp foot goes up by pedal operation after moving
at the sewing start.
-
U039
Execution of origin retrieval every time after completion of
sewing can be performed. (Except cycle stitching)
: Without origin retrieval
: With origin retrieval
-
U040
Setting of origin retrieval in cycle stitching can be set
: Without origin retrieval
: Every time 1 pattern is completed
: Every time 1 cycle is completed
-
U041
State of work clamp foot when machine stopped by temporary
stop command can be selected
: Work clamp foot goes up.
: Work clamp foot goes up with work clamp foot switch.
: Lift of work clamp foot is prohibited.
-
U042
Needle bar stop position is set
: UP position
: Upper dead point
- Needle bar rotates in
the reverse direction af-
ter the UP position stop
and stops when upper
dead point stop is set.
U046
Thread trimming can be prohibited
: Normal : Thread trimming prohibited
-
U048
Route of origin return by means of clear key can be selected
: Straight line return
: Reverse return of pattern
- This function is used
when straight line
return from the midway
of pattern to the start of
sewing is not possible.
U049
Bobbin winding speed can be set
800 to 2000 1600 Max. speed limitation
has priority.
To Next Page
