Figure 98: Crypto Accelerator Module Location on J4350 and J6350 Routers
To modify a Crypto Accelerator Module configuration, use the following procedures:
■ Removing a J4350 or J6350 Crypto Accelerator Module on page 202
■ Installing a J4350 or j6350 Crypto Accelerator Module on page 204
Removing a J4350 or J6350 Crypto Accelerator Module
NOTE: If you are installing a Crypto Accelerator Module into a J4350 Services Router
for the first time, proceed directly to “Installing a J4350 or j6350 Crypto Accelerator
Module” on page 204.
To remove the Crypto Accelerator Module:
1. Place an electrostatic bag or antistatic mat on a flat stable surface to receive the
Crypto Module.
2. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist and
connect the strap to the ESD point on the chassis, or to an outside ESD point if
the router is disconnected from earth ground. For more information about ESD,
see “Preventing Electrostatic Discharge Damage” on page 251.
3. Press and release the power button to power off the Services Router. Wait for
the POWER LED to turn off.
4. Unplug the power cord or cable from the power source receptacle.
5. Remove the screws from the sides and the top of the chassis, and slide the cover
off the chassis.
202 ■ Replacing Crypto Accelerator Modules on J4350 and J6350 Routers
