Table 71: 2-Port Serial PIM Cables and Connectors (continued)
Pinouts
End-to-End
ConductorsConnector HardwareConnectorName
Table 76 on page 228234-40 threaded
jackscrews
DB-25 maleEIA-530A DTE
Table 77 on page 229224-40 threaded jacknutsDB-25 femaleEIA-530A DCE
Table 78 on page 23018Standard (Normally
included with M/34
connector shell)
M/34 maleV.35 DTE
Table 79 on page 23118Standard (Normally
included with M/34
connector shell)
M/34 femaleV.35 DCE
Table 80 on page 23113M3 threaded jackscrewsDB-15 maleX.21 DTE
Table 81 on page 23213M3 threaded jacknutsDB-15 femaleX.21 DCE
RS-232 DTE Cable Pinout
Table 72: RS-232 DTE Cable Pinout
DescriptionLFH-60 PairingDB-25 PinLFH-60 Pin
Frame Ground–115
Transmit Data–260
Receive Data–31
Request to Send–448
Clear to Send–537
Data Set Ready–69
Signal Ground–757
Data Carrier Detect–813
Transmit Clock–1556
Receive Clock–175
Local Loopback–1841
Data Terminal Ready–2033
Terminal Clock–2452
–––22 to 21
224 ■ Serial PIM Cable Specifications
